General Description
These 8-bit registers feature totem-pole 3-STATE outputs designed
specifically for driving highly-capacitive or relatively
low-impedance loads. The high-impedance state and increased
high-logic-level drive provide these registers with the capability
of being connected directly to and driving the bus lines in a
bus-organized system without need for interface or pull-up
components. They are particularly attractive for implementing
buffer registers, I/O ports, bidirectional bus drivers, and working
registers.
Features
■ Choice of 8 latches or 8 D-type flip-flops in a single package
■ 3-STATE bus-driving outputs
■ Full parallel-access for loading
■ Buffered control inputs
■ P-N-P input reduce D-C loading on data lines
Specifications
| Attribute | Attribute Value |
|---|
| Manufacturer | onsemi |
| Product Category | Latches |
| Series | 74S |
| Packaging | Tube |
| Package-Case | 20-DIP (0.300", 7.62mm) |
| Operating-Temperature | 0°C ~ 70°C |
| Mounting-Type | Through Hole |
| Output-Type | Tri-State |
| Voltage-Supply | 4.75 V ~ 5.25 V |
| Supplier-Device-Package | 20-DIP |
| Circuit | 1899/12/30 8:08:00 |
| Current-Output-High-Low | 6.5mA, 20mA |
| Logic-Type | D-Type Transparent Latch |
| Independent-Circuits | 1 |
| Delay-Time-Propagation | 12ns |
Form,Package,Functional compatible component
Descriptions
D-Type Transparent Latch 1 Channel 8:8 IC Tri-State 20-PDIP
