General Description
The MM74HC540 and MM74HC541 3-STATE buffers utilize advanced
silicon-gate CMOS technology. They possess high drive current
outputs which enable high speed operation even when driving large
bus capacitances. These circuits achieve speeds comparable to low
power Schottky devices, while retaining the advantage of CMOS
circuitry, i.e., high noise immunity, and low power consumption.
Both devices have a fanout of 15 LS-TTL equivalent inputs.
Features
■ Typical propagation delay: 12 ns
■ 3-STATE outputs for connection to system buses
■ Wide power supply range: 2–6V
■ Low quiescent current: 80 PA maximum (74HC Series)
■ Output current: 6 mA
Specifications
| Attribute | Attribute Value |
|---|
| Manufacturer | onsemi |
| Product Category | Buffers, Drivers, Receivers, Transceivers |
| Series | 74HC |
| Packaging | Tube |
| Package-Case | 20-DIP (0.300", 7.62mm) |
| Operating-Temperature | -40°C ~ 85°C |
| Mounting-Type | Through Hole |
| Voltage-Supply | 2 V ~ 6 V |
| Supplier-Device-Package | 20-DIP |
| Number-of-Elements | 1 Element |
| Current-Output-High-Low | 7.8mA, 7.8mA |
| Logic-Type | Buffer/Line Driver, Non-Inverting |
| Number-of-Bits-per-Element | 8 |
Form,Package,Functional compatible component
Descriptions
Buffer, Non-Inverting 1 Element 8 Bit per Element Push-Pull Output
20-PDIP
Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin PDIP W Rail
