LFE2-12E-5TN144C Datasheet
Product Details
General Description
The AME8510/8520/8530 family allows the user to customize the CPU
monitoring function without any external components. The user has a
large choice of reset voltage thresholds and output driver
configurations, all of which are preset at the factory. Each wafer
is trimmed to the customers specifications.
Features
● Small packages: SOT-25
● 7 voltage threshold options
● Tight voltage threshold tolerance ---±1.50%
● 12 output driver configuration options
● Wide temperature range -------- -40°C to 85°C
● Low temperature coefficient --- 100ppm/o(max)
● Low quiescent current < 3.0µA
● 3 bonding options
Applications
● Motherboards
● Computer peripherals
● Portable electronics
● Applications using CPUs
● Consumer electronics
Specifications
| Attribute | Attribute Value |
|---|
| Manufacturer | Lattice Semiconductor |
| Product Category | FPGAs (Field Programmable Gate Array) |
| Series | ECP2 |
| Product | ECP2 |
| Packaging | Tray |
| Unit-Weight | 0.046530 oz |
| Mounting-Style | SMD/SMT |
| Package-Case | 144-LQFP |
| Operating-Temperature | 0°C ~ 85°C (TJ) |
| Mounting-Type | Surface Mount |
| Voltage-Supply | 1.14 V ~ 1.26 V |
| Supplier-Device-Package | 144-TQFP (20x20) |
| IC Number of Gates | - |
| Number-of-I-O | 93 I/O |
| Number-of-LABs-CLBs | 1500 |
| Number-of-Logic-Elements-Cells | 12000 |
| Total-RAM-Bits | 226304 Bits |
| Maximum Operating Temperature | + 85 C |
| Operating temperature range | 0 C |
| Operating-Supply-Voltage | 1.2 V |
| Package-Case | TQFP-144 |
| Input/output | 93 I/O |
| Number-of-Logic-Array-Blocks-LABs | 1500 |
| Number-of-Logic-Elements | 12000 Logic Elements |
| Total-Memory | 245 kbit |
| Embedded-Block-RAM-EBR | 221 kbit |
| Distributed-RAM | 24 kit |
Form,Package,Functional compatible component
Descriptions
IC FPGA 93 I/O 144TQFP
FPGA LatticeECP2 Family 12000 Cells 90nm Technology 1.2V 144-Pin
TQFP Tray
FPGA - Field Programmable Gate Array 12K LUTs 93 I/O DSP 1.2V -5
Spd
