EP4CE22F17C8N Programmable Logic ICs FPGA - Field Programmable Gate Array

    Buy cheap EP4CE22F17C8N Programmable Logic ICs FPGA - Field Programmable Gate Array from wholesalers

    Buy cheap EP4CE22F17C8N Programmable Logic ICs FPGA - Field Programmable Gate Array from wholesalers
    • Buy cheap EP4CE22F17C8N Programmable Logic ICs FPGA - Field Programmable Gate Array from wholesalers

    EP4CE22F17C8N Programmable Logic ICs FPGA - Field Programmable Gate Array

    Ask Lasest Price
    Brand Name : Intel / Altera
    Model Number : EP4CE22F17C8N
    Certification : ROHS
    Price : Contact us !
    Payment Terms : Paypal, Western Union, TT
    Supply Ability : 50000 Pieces per Day
    Delivery Time : Send email to learn lead time
    • Product Details
    • Company Profile

    EP4CE22F17C8N Programmable Logic ICs FPGA - Field Programmable Gate Array

    EP4CE22F17C8N Datasheet
    Product Details

    Altera’s new Cyclone® IV FPGA device family extends the Cyclone FPGA series leadership in providing the market’s lowest-cost, lowest-power FPGAs, now with a transceiver variant. Cyclone IV devices are targeted to high-volume, cost-sensitive applications, enabling system designers to meet increasing bandwidth requirements while lowering costs.


    Cyclone IV Device Family Features

    The Cyclone IV device family offers the following features:
    ■ Low-cost, low-power FPGA fabric:
    ■ 6K to 150K logic elements
    ■ Up to 6.3 Mb of embedded memory
    ■ Up to 360 18 × 18 multipliers for DSP processing intensive applications
    ■ Protocol bridging applications for under 1.5 W total power
    ■ Cyclone IV GX devices offer up to eight high-speed transceivers that provide:
    ■ Data rates up to 3.125 Gbps
    ■ 8B/10B encoder/decoder
    ■ 8-bit or 10-bit physical media attachment (PMA) to physical coding sublayer (PCS) interface
    ■ Byte serializer/deserializer (SERDES)
    ■ Word aligner
    ■ Rate matching FIFO
    ■ TX bit slipper for Common Public Radio Interface (CPRI)
    ■ Electrical idle
    ■ Dynamic channel reconfiguration allowing you to change data rates andprotocols on-the-fly
    ■ Static equalization and pre-emphasis for superior signal integrity
    ■ 150 mW per channel power consumption
    ■ Flexible clocking structure to support multiple protocols in a single transceiver block
    ■ Cyclone IV GX devices offer dedicated hard IP for PCI Express (PIPE) (PCIe) Gen 1:
    ■ ×1, ×2, and ×4 lane configurations
    ■ End-point and root-port configurations
    ■ Up to 256-byte payload
    ■ One virtual channel
    ■ 2 KB retry buffer
    ■ 4 KB receiver (Rx) buffer
    ■ Cyclone IV GX devices offer a wide range of protocol support:
    ■ PCIe (PIPE) Gen 1 ×1, ×2, and ×4 (2.5 Gbps)
    ■ Gigabit Ethernet (1.25 Gbps)
    ■ CPRI (up to 3.072 Gbps)
    ■ XAUI (3.125 Gbps)
    ■ Triple rate serial digital interface (SDI) (up to 2.97 Gbps)
    ■ Serial RapidIO (3.125 Gbps)
    ■ Basic mode (up to 3.125 Gbps)
    ■ V-by-One (up to 3.0 Gbps)
    ■ DisplayPort (2.7 Gbps)
    ■ Serial Advanced Technology Attachment (SATA) (up to 3.0 Gbps)
    ■ OBSAI (up to 3.072 Gbps)
    ■ Up to 532 user I/Os
    ■ LVDS interfaces up to 840 Mbps transmitter (Tx), 875 Mbps Rx
    ■ Support for DDR2 SDRAM interfaces up to 200 MHz
    ■ Support for QDRII SRAM and DDR SDRAM up to 167 MHz
    ■ Up to eight phase-locked loops (PLLs) per device
    ■ Offered in commercial and industrial temperature grades

    Specifications

    AttributeAttribute Value
    ManufacturerIntel / Altera
    Product CategoryFPGAs (Field Programmable Gate Array)
    SeriesCyclone® IV E
    ProductCyclone IV E
    PackagingTray
    Mounting-StyleSMD/SMT
    TradenameCyclone IV
    Package-Case256-LBGA
    Operating-Temperature0°C ~ 85°C (TJ)
    Mounting-TypeSurface Mount
    Voltage-Supply1.15 V ~ 1.25 V
    Supplier-Device-Package256-FBGA (17x17)
    IC Number of Gates-
    Number-of-I-O153 I/O
    Number-of-LABs-CLBs1395
    Number-of-Logic-Elements-Cells22320
    Total-RAM-Bits608256 Bits
    Maximum Operating Temperature+ 70 C
    Operating temperature range0 C
    Operating-Supply-Voltage1 V to 1.2 V
    Maximum-Operating-Frequency200 MHz
    Package-CaseFBGA-256
    Input/output153 I/O
    Number-of-Logic-Array-Blocks-LABs1395
    Number-of-Logic-Elements22320 Logic Elements
    Total-Memory594 kbit
    Manufacturer Part#DescriptionManufacturerCompare
    EP4CE22F17C6NField Programmable Gate Array, 1395 CLBs, 472.5MHz, 22320-Cell, PBGA256, 17 X 17 MM, 1 MM PITCH, LEAD FREE, FBGA-256Intel CorporationEP4CE22F17C8N vs EP4CE22F17C6N
    Programmable Logic
    EP4CE22F17C7Field Programmable Gate Array, 1395 CLBs, 472.5MHz, 22320-Cell, PBGA256, 17 X 17 MM, 1 MM PITCH, FBGA-256Intel CorporationEP4CE22F17C8N vs EP4CE22F17C7
    Programmable Logic
    EP4CE22F17C7NField Programmable Gate Array, 1395 CLBs, 472.5MHz, 22320-Cell, PBGA256, 17 X 17 MM, 1 MM PITCH, LEAD FREE, FBGA-256Intel CorporationEP4CE22F17C8N vs EP4CE22F17C7N
    Programmable Logic
    EP4CE22F17C6Field Programmable Gate Array, 1395 CLBs, 472.5MHz, 22320-Cell, PBGA256, 17 X 17 MM, 1 MM PITCH, FBGA-256Intel CorporationEP4CE22F17C8N vs EP4CE22F17C6
    Programmable Logic
    EP4CE22F17C8Field Programmable Gate Array, 1395 CLBs, 472.5MHz, 22320-Cell, PBGA256, 17 X 17 MM, 1 MM PITCH, FBGA-256Intel CorporationEP4CE22F17C8N vs EP4CE22F17C8
    Programmable Logic
    EP4CE22F17I7Field Programmable Gate Array, 1395 CLBs, 472.5MHz, 22320-Cell, PBGA256, 17 X 17 MM, 1 MM PITCH, FBGA-256Intel CorporationEP4CE22F17C8N vs EP4CE22F17I7
    Programmable Logic
    EP4CE22F17A7NField Programmable Gate Array, 1395 CLBs, 472.5MHz, 22320-Cell, PBGA256, 17 X 17 MM, 1 MM PITCH, LEAD FREE, FBGA-256Intel CorporationEP4CE22F17C8N vs EP4CE22F17A7N
    Programmable Logic
    EP4CE22F17I7NField Programmable Gate Array, 1395 CLBs, 472.5MHz, 22320-Cell, PBGA256, 17 X 17 MM, 1 MM PITCH, LEAD FREE, FBGA-256Intel CorporationEP4CE22F17C8N vs EP4CE22F17I7N
    Programmable Logic
    EP4CE22F17C8NField Programmable Gate Array, 1395 CLBs, 472.5MHz, 22320-Cell, PBGA256, 17 X 17 MM, 1 MM PITCH, LEAD FREE, FBGA-256Intel CorporationEP4CE22F17C8N vs EP4CE22F17C8N
    Programmable Logic

    Descriptions

    FPGA Cyclone庐 IV E Family 22320 Cells 60nm Technology 1.2V 256-Pin TFBGA
    FPGA - Field Programmable Gate Array FPGA - Cyclone IV E 1395 LABs 153 IOs
