AOZ8914CI Datasheet

Product Details

General Description

The AOZ8900 is a transient voltage suppressor array designed to protect high speed data lines from Electro Static Discharge (ESD) and lightning. This device incorporates eight surge rated, lowcapacitance steering diodes and a Transient Voltage Suppressor (TVS) in a single package. During transient conditions, the steering diodes direct the transient to either the positive side of the power supply line or to ground. They may be used to meet the ESD immunity requirements of IEC 61000-4-2, Level 4 (±15kV air, ±8kV contact discharge). The AOZ8900 comes in RoHS compliant SOT-23 package. It is rated over a -40°C to +85°C ambient temperature range.

Features

●ESD protection for high-speed data lines:
–Exceeds: IEC 61000-4-2 (ESD) ±15kV (air), ±8kV (contact)
–IEC 61000-4-5 (Lightning) 5A (8/20µs)
–Human Body Model (HBM) ±15kV
●Small package saves board space
●Low insertion loss
●Protects four I/O lines
●Low clamping voltage
●Low operating voltage: 5.0V
