MAX192ACAP+ Analog to Digital Converters - ADC Low-Power, 8-Channel, Serial 10-Bit ADC

    Buy cheap MAX192ACAP+ Analog to Digital Converters - ADC Low-Power, 8-Channel, Serial 10-Bit ADC from wholesalers

    Buy cheap MAX192ACAP+ Analog to Digital Converters - ADC Low-Power, 8-Channel, Serial 10-Bit ADC from wholesalers
    • Buy cheap MAX192ACAP+ Analog to Digital Converters - ADC Low-Power, 8-Channel, Serial 10-Bit ADC from wholesalers
    • Buy cheap MAX192ACAP+ Analog to Digital Converters - ADC Low-Power, 8-Channel, Serial 10-Bit ADC from wholesalers

    MAX192ACAP+ Analog to Digital Converters - ADC Low-Power, 8-Channel, Serial 10-Bit ADC

    Ask Lasest Price
    Brand Name : Maxim Integrated
    Model Number : MAX192ACAP+
    Certification : ROHS
    Price : Contact us !
    Payment Terms : Paypal, Western Union, TT
    Supply Ability : 50000 Pieces per Day
    Delivery Time : Send email to learn lead time
    • Product Details
    • Company Profile

    MAX192ACAP+ Analog to Digital Converters - ADC Low-Power, 8-Channel, Serial 10-Bit ADC

    MAX192ACAP+ Datasheet

    Product Details

    General Description

    The MAX192 is a low-cost, 10-bit data-acquisition system that combines an 8-channel multiplexer, high-bandwidth track/hold, and serial interface with high conversion speed and ultra-low power consumption. The device operates with a single +5V supply. The analog inputs are software configurable for single-ended and differential (unipolar/bipolar) operation.


    Features

    ♦ 8-Channel Single-Ended or 4-Channel Differential Inputs
    ♦ Single +5V Operation
    ♦ Low Power: 1.5mA (operating)
    2µA (power-down)
    ♦ Internal Track/Hold, 133kHz Sampling Rate
    ♦ Internal 4.096V Reference
    ♦ 4-Wire Serial Interface is Compatible with SPI, QSPI, Microwire, and TMS320
    ♦ 20-Pin DIP, SO, SSOP Packages
    ♦ Pin-Compatible 12-Bit Upgrade (MAX186/MAX188)


    Applications

    Automotive
    Pen-Entry Systems
    Consumer Electronics
    Portable Data Logging
    Robotics
    Battery-Powered Instruments, Battery
    Management
    Medical Instruments

    Specifications

    AttributeAttribute Value
    ManufacturerMaxim Integrated
    Product CategoryIC Chips
    SeriesMAX192A
    ProductAnalog to Digital Converters
    TypeData Acquisition System (DAS), ADC
    PackagingTube Alternate Packaging
    Unit-Weight0.016000 oz
    Mounting-StyleSMD/SMT
    Package-Case20-SSOP (0.209", 5.30mm Width)
    Input-TypeDifferential/Single-Ended
    Operating-Temperature0°C ~ 70°C
    Mounting-TypeSurface Mount
    Number-of-Channels8 Channel
    Voltage-Supply±5V
    Supplier-Device-Package20-SSOP
    Resolution-Bits10 b
    Sampling-Rate-Per-Second133k
    Data-InterfaceMICROWIRE?, QSPI?, Serial, SPI?
    Voltage-Supply-SourceSingle Supply
    ArchitectureSAR
    Resolution10 bit
    Reference-TypeExternal Internal
    Pd-Power-Dissipation640 mW
    Maximum Operating Temperature+ 70 C
    Operating temperature range0 C
    Interface-TypeSerial 4-Wire SPI TMS320
    Part-#-AliasesMAX192A
    Package-CaseSSOP-20
    Number-of-Converters1 Converter
    Sampling-Rate133 kS/s
    INL-Integral-Nonlinearity+/- 0.5 LSB
    Reference-Voltage4.096 V
    DNL-Differential-Nonlinearity+/- 1 LSB

    Descriptions

    Data Acquisition System (DAS), ADC 10 bit 133k MICROWIRE?, QSPI?, Serial, SPI? 20-SSOP
    Analog to Digital Converters - ADC 10-Bit 8Ch 133ksps 5V Precision ADC
