SPC5606BK0MLU6
Datasheet
Product Details
Description
This family of 32-bit system-on-chip (SoC) microcontrollers is the
latest achievement in integrated automotive application
controllers. It belongs to an expanding family of
automotive-focused products designed to address the next wave of
body electronics applications within the vehicle.
MPC5607B Microcontroller Data Sheet
• Single issue, 32-bit CPU core complex (e200z0h)
— Compliant with the Power Architecture®
technology embedded category
— Enhanced instruction set allowing variable
length encoding (VLE) for code size footprint
reduction. With the optional encoding of mixed
16-bit and 32-bit instructions, it is possible to
achieve significant code size footprint
reduction.
• Up to 1.5 MB on-chip code flash memory supported
with the flash memory controller
• 64 (4 × 16) KB on-chip data flash memory with ECC
• Up to 96 KB on-chip SRAM
• Memory protection unit (MPU) with 8 region
descriptors and 32-byte region granularity on certain
family members (Refer to Table 1 for details.)
• Interrupt controller (INTC) capable of handling 204
selectable-priority interrupt sources
• Frequency modulated phase-locked loop (FMPLL)
• Crossbar switch architecture for concurrent access to
peripherals, Flash, or RAM from multiple bus
masters
• 16-channel eDMA controller with multiple transfer
request sources using DMA multiplexer
• Boot assist module (BAM) supports internal Flash
programming via a serial link (CAN or SCI)
• Timer supports I/O channels providing a range of
16-bit input capture, output compare, and pulse
width modulation functions (eMIOS)
• 2 analog-to-digital converters (ADC): one 10-bit and
one 12-bit
• Cross Trigger Unit to enable synchronization of
ADC conversions with a timer event from the
eMIOS or PIT
• Up to 6 serial peripheral interface (DSPI) modules
• Up to 10 serial communication interface (LINFlex)
modules
• Up to 6 enhanced full CAN (FlexCAN) modules
with configurable buffers
• 1 inter-integrated circuit (I2C) interface module
• Up to 149 configurable general purpose pins
supporting input and output operations (package
dependent)
• Real-Time Counter (RTC)
— Clock source from internal 128 kHz or 16 MHz
oscillator supporting autonomous wakeup with
1 ms resolution with maximum timeout of 2
seconds
— Optional support for RTC with clock source
from external 32 kHz crystal oscillator,
supporting wakeup with 1 sec resolution and
maximum timeout of 1 hour
• Up to 8 periodic interrupt timers (PIT) with 32-bit
counter resolution
• Nexus development interface (NDI) per IEEE-ISTO
5001-2003 Class Two Plus
• Device/board boundary scan testing supported per
Joint Test Action Group (JTAG) of IEEE (IEEE
1149.1)
• On-chip voltage regulator (VREG) for regulation of
input supply for all internal levels
Specifications
| Attribute | Attribute Value |
|---|
| Manufacturer | NXP / Freescale |
| Product Category | Microcontrollers |
| Manufacturer | NXP |
| Product-Category | 32-bit Microcontrollers - MCU |
| RoHS | Details |
| Packaging | Tray |
| Brand | NXP / Freescale |
| Unit-Weight | 0.065909 oz |
| |
Descriptions
* Microcontroller IC
MCU 32-bit e200 RISC 1MB Flash 3.3V/5V Automotive 176-Pin LQFP Tray
32-bit Microcontrollers - MCU Freescale 32-bit MCU, Power Arch
core, 1MB Flash, 64MHz, -40/+125degC, Automotive Grade, QFP 176
